CRS326-24S+2Q+RM

Part: CRS326-24S+2Q+RM



SWITCHES

Our fastest switch for the most demanding setups

Original price was: C$ 807.66.Current price is: C$ 733.25.

Only 1 left in stock

Ordered:15
Items available:1

Guaranteed Safe Checkout

Features & Compatibility

If you are working with substantial amount of data – like providing Internet access or maintaining a huge data center – this is the perfect upgrade for your setup. CRS326-24S+2Q+RM is our first product with 40 Gbps QSFP+ ports for remarkably fast and stable fiber connection.

Overall it has two 40 Gbps QSFP+ ports and twenty four 10 Gbps SFP+ ports, which provides total nonblocking throughput of 320 Gbps and switching capacity of 640 Gbps with forwarding rate of 252 Mpps with most common packets.

CRS326-24S+2Q+RM is easy to manage – it has a full size USB port for configuration and dual power supply for redundancy – no unexpected downtime, your clients and colleagues will be thankful!

You can choose between our legendary feature-packed RouterOS for booting or a simpler, but still powerful SwOS. If you would like the ability to use routing and other Layer 3 features in your CRS, use RouterOS

Specifications

Details
Product code CRS326-24S+2Q+RM
Architecture MIPSBE
CPU QCA9531
CPU core count 1
CPU nominal frequency 650 MHz
Switch chip model 98DX8332
Dimensions 443 x 200 x 44 mm
RouterOS license 5
Operating System RouterOS v7 / SwitchOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -20°C to 60°C
Suggested price

Powering

Details
Number of AC inputs 2
AC input range 100-240
Max power consumption 69 W
Max power consumption without attachments 42 W
Cooling type 3 fans

Ethernet

Details
10/100 Ethernet ports 1

Fiber

Details
SFP+ ports 24
Number of 40G QSFP+ ports 2

Peripherals

Details
Serial console port RJ45
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1

Certification & Approvals

Details
Certification CE, EAC, ROHS
IP IP20

Additional information

Weight 1.7 kg
Dimensions 2.79 × 24 × 16 cm
Brand

Mikrotik
