XZ000-G7

1-Port Gigabit XPON Terminal

C$ 25.00

Call for availability

Guaranteed Safe Checkout

Features & Compatibility

  • Gigabit Internet Access: One PON port and one gigabit LAN port provide fast transfer speeds*
  • XPON Support: EPON + GPON dual mode offers greater flexibilty for fiber internet access
  • Durability: Intelligent power-saving method
  • Remote Management: Supports the OMCI (ONU Management Control Interface) protocol for centralized configuration and management.

HARDWARE FEATURES
Interface 1 PON Port
1 10/100/1000 Mbps RJ45 Port
Button 1 RESET Button
External Power Supply 9VDC/0.6A
IEEE Standards IEEE 802.3, 802.3u, 802.1p, 802.1Q
Data Rates Downstream Speeds: 2.488 Gbps (GPON), 1.25 Gbps (EPON)*
Upstream Speeds: 1.244 Gbps (GPON), 1.25 Gbps (EPON)*
Wavelength Upstream: 1310 nm
Downstream: 1490 nm
Dimensions ( W x D x H ) 3.7 x 3.0 x 1.2 in. (95.0 x 75.0 x 29.3 mm)
Distance 0–20 Km Max
GPON Standards ITU-T G.988, G.984.1, G.984.2, G.984.3, G.984.4
Optical Module Class B+
Receiver Super-TIA
Transmitter DFB Laser
SOFTWARE FEATURES
Advanced Features Upstream and Downstream FEC,
Dynamic Bandwidth Allocation(DBA) support NSR/SR,
Up to 16 T-CONTs and 256 GEM Ports,
Optical power detection,
Dying Gasp,
Terminal Silent mechanism
VLAN 802.1Q tag VLAN, VLAN transparent mode/VLAN translation mode/VLAN trunk mode, Authentication based on SN and Password, VLAN Auto Detect
Security AES Encryption, Packet Filter based on VLAN
Management Local management: WebGUI, Telnet
Remote management: OMCI
IGMP IGMP v1/v2/v3
OTHERS
Package Contents XZ000-G7
Power Adapter
Requirements Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Subscription with an internet service provider (for internet access)
Certifications CE, RoHS
Environment Operating Temperature: 0℃–40℃ (32℉–104℉)
Storage Temperature: -40℃–60℃ (-40℉–140℉)
Operating Humidity: 10%–90% non-condensing
Storage Humidity: 5%–90% non-condensing

Additional information

Weight .450 kg
Dimensions 16.5 × 12.7 × 12.7 cm
Brand

TP-Link
