Mimosa N5-X20 4.9-6.4GHz Connectorized 2×2 Access Point 250mm Modular Twist-on Dish Antenna (2 Pack)

Part: 100-00088

C$ 88.99

Guaranteed Safe Checkout

Features & Compatibility

MORE INFORMATION

PRODUCT SPECIFICATIONS

2 Units of Antenna 20dbi gain Mimosa N5-X20 Dish is the industry’s most versatile, modular, radio solution with five gain options (8, 12, 16, 20 and 25 dBi). The ultra-rugged solution provides extended frequency operation from 4.9GHz – 6.4GHz, with best-in-class noise immunity. Delivering the ultimate in flexibility and value, the C5x is the go-to solution for 5GHz deployments. Out of the box, the C5x can be used in PTMP mode, with Ethernet link speeds of up to 100 Mbps. With the purchase of a PTMP speed feature key, speeds of up to 500 Mbps will be unlocked in PTMP mode. In order to unlock and utilize PTP mode, with speeds of up to 700 Mbps, a PTP feature key must be purchased.

  • Key Applications
    • Broadband service providers
    • Public safety and first responders
    • Enterprise and campus building interconnecting
    • Multipoint distribution for WiFi, video security and Smart Cities
  • Key Features
    • Four Twist-On, Flexible Antenna Options
    • PTP or PTMP Modes (feature key may be required)
    • Extended Frequency 4.9–6.4 GHz
    • Best-in-Class Noise Immunity
    • Ultra Rugged
    • Low-Power Consumption
    • Ultra Reliable
  • Integrated Radio with Modular Antenna Options
    • The C5x radio’s native 8 dBi gain can be increased to 12, 16, 20 or 25 dBi using Mimosa’s modular, N5-X, twist-on antennas, offering the ease and simplicity of integrated radios, but with so much more flexibility!
  • Incredible RF Performance
    • Available with either Cassegrain or horn antenna options, the C5x reduces localized noise and provides immunity from interference with breakthrough front-to-back and front-to-side performance. Each antenna in the N5-X family is optimized to isolate noise with incredible sidelobe rejection.
  • Ultra Rugged
    • The C5x, with its die-cast aluminum metal enclosure, dual pole mounts, and industrial-grade twist-on antenna options, is custom-engineered to reduce noise, withstand the outdoor elements and stay mounted in harsh wind and extreme weather.
  • Extended Frequency 4.9–6.4 GHz
    • To escape the noise, the C5x lets you take advantage of licensed frequencies from 4.9 GHz up to 6.4 GHz, where allowed by local regulations, including the public safety band in the US. The custom-designed N5-X modular antennas are specifically optimized for C5x extended frequency support.

Dimensions

  • Diameter: 270 mm (10.63”)
  • Depth: 83mm (3.27”)

Weight

  • 0.77 kg (1.70lbs)

Technical Description

  • Product: N5-X20
    • Gain: 20dBi
    • Polarization: Dual-Slant 45°
    • Beamwidth, Symmetric (3dB): 12°
    • Front-to-Back (min): 35dB
    • Front-to-Side Ratio: 37dB
    • Mount: Mimosa N5-X twist-on
    • Wind Survivability: 200 km/h (125 mph)
    • Wind Loading: 14.55 @160 km/h (32.07lbs @ 100 mph)
    • Operating Temperature: -40°C to +55°C (-40°F to 131°F)
  • Product Includes:
    • (2) N5-X20 Dish
    • (1) User Manual
