Mimosa Advanced J-Mount support for C5

The Mimosa Advanced J-Mount accessory accommodates most under roof eave mounting applications. With an extra axis of rotation to align the C5 and keep it level to the horizon, the J-Mount provides three degrees of rotation for elevation, azimuth and pole twist adjustment for precise aiming.

Dimensions

• Mounting Base:
  • 191 mm (7.52“) x 120 mm (4.72“)
• Pole Length:
  • 355 mm (14“)
• Pole Outside Diameter:
  • 38 mm (1.5“)

Weight

• 0.96 kg (33.8 oz)

Technical Description

• Mounting Options: Surface mount with four screw hole points.
• Assembly: Pre-assembled with a white powder coated finish; Includes four (4) 6.35 mm (0.25”) lag bolts.
• Pipe/hose clamps not included
