Specifications
- Product code CRS812-8DS-2DQ-2DDQ-RM
- Architecture ARM 64bit
- CPU AL 52400
- CPU core count 4
- CPU nominal frequency 2000 MHz
- CPU Threads count 4
- Switch chip model 98DX7335
- Router OS license 6
- Operating System Router OS v7
- Size of RAM 4 GB
- Storage size 512 MB
- Storage type NAND
- MTBF Approximately 200’000 hours at 25°C
- Tested ambient temperature -10°C to 50°C
Powering
- Number of AC inputs 2
- AC input range 100–240 V
- Number of PSU slots 2
- Frequency (Hz) 50–60
- Max power consumption 134 W
- Max power consumption without attachments 81 W
- Cooling type 4 fans
Ethernet
- Number of 1G/2.5G/5G/10G Ethernet ports 2 (supported: 10M/100M/1G/10G)
- Number of 50G SFP 56 ports8
- Number of 200G QSFP 56 ports2
- Number of 400G QSFP 56-DD ports2
Peripherals
- Serial console port RJ45
Other
- CPU temperature monitor Yes
- PCB temperature monitor Yes
- Voltage Monitor Yes
Certification & Approvals
- Certification CE, EAC, ROHS
- IP20
